MODULAR THROTTLE AND CHECK VALVE
MT-04 SERIES
The modular adjustable flow
control valve functions as a needle valve flow restrictor in one
direction
in a branch of a circuit, with free flow in the opposite
direction. It operates on the A & B ports in the “meter-out”
configuration. Adjustment is made with a calibrated knob,
standard with the valve.
As a modular valve, this valve mounts between an NFPA D07 size
directional control valve and the subplate. A longer than
standard bolt kit is required when mounting modular valves in a
stack. Refer to bolt kits.
|
|
 |
|
 |
|
|
